Pump Maintenance Checklist: Daily, Monthly, Annual Tasks

A pump that costs ₹50,000 today, if maintained, will run reliably for 10–15 years. Without maintenance, it fails in 18 months — costing 5–10× more in downtime, energy, and replacements. The good news: preventive maintenance is simple and the tasks divide neatly into daily, monthly, and annual buckets. This checklist gives you the practical schedule.

1. Daily Checks (5 Minutes)

For mission-critical pumps running 24/7, do these at the start of every shift:

• Vibration: Touch the bearing housing. Excessive vibration or unusual smoothness changes are early warnings. Document any change.
• Temperature: Feel bearing housings — should be hand-warm (under 60°C). Anything hot to touch suggests bearing failure, misalignment, or lubricant issues.
• Sound: Listen for changes. Gravel-like noise → cavitation. Whining → bearing wear. Grinding → mechanical contact.
• Pressure gauges: Discharge pressure stable. Erratic readings → cavitation or air ingress.
• Leakage: Mechanical seal or gland should have minimal drip (gland-packed pumps allow few drops per minute; mechanical seals should be dry).
• Motor current: Compare against last week's normal — increased current suggests increased load or impeller wear.

2. Weekly Tasks (15 Minutes)

• Clean dust and grime off motor cooling fins (TEFC motors run hotter when dust-blocked)
• Check coupling guard — ensure it's in place and secure
• Verify drain line from gland is clear
• Inspect mounting bolts for looseness (especially after first 4 weeks of new pump)
• Check level in oil-lubricated bearings (top up with same grade oil if needed)

3. Monthly Maintenance (30 Minutes)

• Vibration analysis: If you have a handheld vibration analyser, log overall vibration (mm/s RMS) on each bearing. Trend it against history.
• Re-grease bearings: Grease-lubricated bearings need a small charge (typically 5–10 grams) at monthly intervals. Over-greasing is worse than no greasing.
• Inspect gland packing: Tighten or replace if leakage exceeds spec.
• Strainer cleaning: Pull and clean the suction strainer.
• Visual coupling inspection: Look for rubber/jaw wear, missing inserts.
• Pump pressure & flow logging: If you have meters, log the duty point and compare to design curve.
• Motor IR test: Megger test of motor winding (typically >100 MΩ for HV motors, >10 MΩ for LV).

4. Quarterly Tasks

• Mechanical seal flush line check — flow and pressure within spec
• Calibrate pressure gauges
• Inspect baseplate grout and foundation bolts
• Check alignment between pump and motor (laser or dial gauge)
• Inspect anti-vibration mounts if fitted

5. Annual Overhaul (4-8 Hours Down)

• Complete disassembly: Remove pump from baseplate (for major motors and high-criticality pumps; smaller pumps may skip this)
• Bearing replacement: Replace all bearings as a set, regardless of apparent condition
• Mechanical seal inspection: Replace if showing wear; mechanical seals are wear items
• Impeller inspection: Look for cavitation pitting (low-pressure side), wear ring clearance (replace if exceeding 1 mm), balance check
• Casing inspection: Check volute throat for wear, gasket surfaces
• Coupling overhaul: Replace elastomer inserts, re-lubricate gear couplings
• Realignment: After reassembly, laser-align to <0.05 mm
• Motor overhaul: Bearings replaced, varnish refresh (if shop allows), IR and surge test
• Painting: Touch up exterior paint to prevent corrosion

6. Spare Parts to Stock

To minimise downtime, keep these on the shelf for each pump model in service:

• Mechanical seal assembly (or gland packing)
• Bearings (drive end and non-drive end)
• Wear ring(s)
• Casing gasket and gasket sheet stock
• Coupling elastomer / jaw set
• Impeller (for critical pumps)

7. Documentation

Maintain a logbook for each pump containing: original commissioning data, performance curve, baseline vibration and temperature, alignment records, parts replaced and dates, and any abnormal events. This pays off massively during troubleshooting and when planning replacement.
